2MP 1080P 12mm lens MJPEG 120fps@640x480 USB2.0 hd industrial uvc usb camera module with 42x42x42mm mini case
2.0 megapixel 8mm lens MJPEG 120fps@640x480 USB2.0 hd industrial usb camera module with 42x42x42mm black case
Specification:
|
Optional models |
ELP-USBFHD01M-L21B(2.1mm lens) ELP-USBFHD01M-L28B(2.8mm lens) ELP-USBFHD01M-L36B(3.6mm lens) ELP-USBFHD01M-L60B(6mm lens) ELP-USBFHD01M-L80B(8mm lens) ELP-USBFHD01M-L12B(12mm lens) |
|
Sensor |
1/2.7" CMOS OV2710 |
|
Lens size |
200W, 2.0megapixel, 1920(H)x1080(V)pixels |
|
Max. Resolution |
1920X1080 |
|
Picture format |
MJPEG |
|
USB Protocal |
USB2.0 HS/FS, USB1.1 FS |
|
Support free driver |
USB Video Class(UVC)1.1 |
|
Auto exposure AEC |
Support |
|
Auto white blance AEB |
Support |
|
Frame rate |
1920 (H) x 1080 (V) pixels MJPEG 30fps YUY2 6fps |
|
Adjustable parameters |
Brightness/Contrast/Color saturation /Definition/Gamma/WB |
|
Night vision |
optional, can choose IR board |
|
view angle |
30-150 degree optional |
|
voltage |
DC 5V |
|
current |
150mA |
|
work temperature |
DEGREES(-20~70) |
|
Size |
32x32mm/38*38 |
|
Support OS |
WinXP/Vista/WIN7/WIN8 |
Effective Pixels:
1920 (H) x 1080 (V) pixels
1280 (H) x 1024 (V) pixels
1280 (H) x 720 (V) pixels
1024 (H) x 768 (V) pixels
800 (H) x 600 (V) pixels
640 (H) x 480 (V) pixels
352(H) x 288 (V) pixels
320 (H) x 240 (V) pixels
Performance:
1920 (H) x 1080 (V) pixels MJPEG 30fps YUY2 6fps
1280 (H) x 1024 (V) pixels MJPEG 30fps YUY2 6fps
1280 (H) x 720 (V) pixels MJPEG 60fps YUY2 9fps
1024 (H) x 768 (V) pixels MJPEG 30fps YUY2 9fps
800 (H) x 600 (V) pixels MJPEG 60fps YUY2 21fps
640 (H) x 480 (V) pixels MJPEG 120fps YUY2 30fps
352(H) x 288 (V) pixels MJPEG 120fps YUY2 30fps
320 (H) x 240 (V) pixels MJPEG 120fps YUY2 30fps
Applications
Car and ship control, electronic equipment, oil field equipment, industrial equipment, remote site
monitoring, environmental monitoring, etc.
used for all kinds of machine as below:
machinery equipment, all-in-one machine, POS equipment, STB, smart box TV BOX, advisement player,
LED display, automatic vending machine, safety box, notebook, video door phone, MID, Tablet external,
evaluator, Medical Equipment, on-the-spot law enforcement, door bell and button system, cat-eye system,
simple security system, teaching system, Interactive system, automobile data recorder. Project video capture,
credit card machine, attendance machine, Voting system, High speed video shooting Device, exam system,
Driving learning system, Industrial camera, biological microscope, box inside surveillance, micro HD surveillance,
endoscope, Medical auxiliary equipment, etc.
